The Dynaplus® wood cladding screw has been specially developed for fastening hinges and other fittings to the end face of panel material. In some situations, piano hinges can sometimes be fixed to the end of the sheet material.
Due to the layered construction of sheet material, the end side is very sensitive to expanding or splitting when you screw in it; but not with the Dynaplus® interior panel hardware screw! The unique triangle shaped diamond point at the screw tip provides maximum drilling capacity. This allows you to use these screws without pre-drilling.
This special Wood cladding screw is available in two sizes; 3.5×40 and 4.0×40.
These screws have a small and panhead with a diameter of 6.0 and 7.0 mm, without milling ribs, which is nicely galvanized in drill holes from 3.5 to 5.0 mm. The deep TX-15 drive provides a stable power transmission from the bit to the screw. Due to the small breast area under the screw head, this screw has a higher breaking value in practice; with this it absorbs the impact with which the screw is screwed onto the hinge, so that it does not break off.
A real problem solver for the professional!
Curious about the possibilities? contact us soon!
